Size Range: DN50-DN400
Pressure Range: 1.0MPa-1.6MPa
End Connection: Flanged
Material: Ductile iron, brass components
Seals: NBR/EPDM
Valves Design: Angle-type float-operated design for level control
Face to Face: Compliant with EN558-1 standards
End Connection: ISO 7005-2 Flanged
Testing & Inspection: ISO 5208 compliant
Suitable Medium: Water and non-corrosive fluids
The Angle-Type Remote-Controlled Float Valve is designed to efficiently control liquid levels in storage tanks and reservoirs. Featuring a float-operated mechanism, this valve offers precise level regulation by opening or closing based on water levels. Its angle-type design ensures minimal flow resistance, while durable materials guarantee extended service life in demanding applications.
Angle-type design for enhanced flow efficiency
Float-operated mechanism ensures automatic liquid level control
Constructed with corrosion-resistant materials for long-term reliability
Adjustable design allows flexible installation options
Suitable for water and non-corrosive fluid applications
Design and Manufacturing Standards: ISO 5208, EN 1074-1
Structural Length Standard: EN558-1 Series 1
Connection Forms Standards: ISO 7005-2 (Flanged)
Available Sizes (Caliber): DN50-DN400
Pressure-Temperature Rating:
Standard: PN10, PN16
Pressure Range: 1.0MPa-1.6MPa
Temperature Range: -10°C to 80°C
Municipal and industrial water storage systems
Irrigation systems for precise water level regulation
Reservoirs in power plants and energy facilities
Water treatment plants for consistent liquid management
