Butt Weld Cross

Industries

• Oil & Gas Industry: Widely used in pipelines for oil, natural gas, and petrochemical processing under high-pressure conditions.
• Chemical Industry: Ideal for corrosive chemical transport systems requiring high integrity and resistance to leakages.
• Power Generation: Used in high-temperature steam lines, cooling systems, and other critical applications in power plants.
• Water Treatment: Suitable for connecting pipelines in potable and wastewater treatment plants.
• HVAC Systems: Applied in heating, ventilation, and cooling systems for fluid transport.
• Mining Industry: Utilized in slurry lines, conveying abrasive and aggressive fluids.

Specific Applications

• Steam Distribution Systems: Designed for use in steam piping systems to handle high temperatures and pressures.
• Pipeline Branch Connections: Butt weld tees and branch outlets used to create pipeline branch connections.
• Flow Reduction Applications: Welded reducers are used for changing pipe sizes to control flow rates.
• Pressure Relief Lines: Cross fittings and elbows used to divert flow in pressure relief lines.

Installation Instructions

• Ensure proper alignment of pipes and fittings before welding to prevent stress on joints.
• Use qualified welders and follow standard welding procedures for reliable connections.
• Verify pressure and temperature ratings to ensure the fittings are suitable for the intended application.
• Use appropriate sealing materials, such as PTFE or graphite, where additional sealing is required.
• Inspect all welds for quality and leaks before putting the system into operation.
