Electric V-Type Hemisphere Valve

Design and manufacturing:GB/T 12237, API 6D, ASME B16.34
The structural length:GB/T 12221, ASME B16.10
Connection forms: HG/T 20592-20605, GB/T 9112-9124, ASME B16.5
Inspection and test:API 598, GB/T 13927
Caliber: DN25 ~ DN400
Pressure temperature level: GB/T 12224, ASME B16.34
Drive mode: Electric
Pressure:PN16 ~ PN64

Product Overview

ZDJV and ZKJV series electric regulating ball valves feature a V-shaped ball core. When the valve is closed, the V-notch and the seat form a wedge cut, effectively avoiding the “death phenomenon” caused by residual media between the ball and seat, thus ensuring good sealing performance and flow control accuracy.

These valves:

Provide linear regulation and control over media with pulp, fiber, or small solid particles.
Offer a wide adjustable range, stable cut-off, and low flow resistance.
Are not suitable for general clean fluids, but are ideal for harsh media.

Operating Mechanism (Drive Mode)

Electric Actuation:
- ON/OFF Control: For standard open/close operations
- Modulating Control: Supports 4-20 mA, 0-10 V input signals for precise flow regulation
Features:
- Local Control Panel: For manual override and settings
- Remote Control Capability: Integration with DCS/PLC systems
- Feedback Signals: Position feedback via analog or digital signals
- Optional: Explosion-proof actuators for hazardous environments

Materials

Body Material Options:
- Carbon Steel: WCB, suitable for general applications
- Stainless Steel: CF8 (304), CF8M (316) for corrosion resistance
- Alloy Steel: For high-temperature or high-pressure applications
Trim Materials:
- Ball: Stainless Steel, hard-faced alloys for wear resistance
- Stem: Stainless Steel with optional surface treatments
Seat Materials:
- Soft Seals: PTFE, RPTFE for tight sealing in standard applications
- Metal Seals: Stellite, Inconel for high-temperature and abrasive media

Certifications

API 6D
ISO 9001
CE Marking
PED (Pressure Equipment Directive)
SIL (Safety Integrity Level) certification for critical applications

Product Features

• Trunnion Mounted Design:

Ensures stable operation under high pressure, minimizing torque and enhancing sealing performance.

• Forged Construction:

Offers higher strength and durability for critical applications

• Multi-Way Configurations:

Available in three-way and four-way configurations for complex flow paths, ideal for process industries.

• High-Temperature and High-Pressure Capabilities:

Specifically designed for severe conditions, available in high-temperature and high-pressure models

• Compact and Sanitary Designs:

Available for cleanroom, pharmaceutical, and food industry applications

Specification Parameters

◇ Main Technical Parameters and Performance

Valve Type:
Through casting ball valve

Nominal Diameter (DN):

DN (mm)	25	32	40	50	65	80	100	125	150	200	250	300	350	400
Seat Diameter (mm)	20	26	33	40	53	66	85	104	128	170	212	256	300	340
Rated Flow Coefficient (Kv)	25	36	63	100	184	284	400	600	950	1540	2250	3900	6150	9800

Nominal Pressure:
PN1.6, 6.4 MPa

◇ Additional Technical Details

Item	Specification
Connection Type	Wafer type, flange type; Standard JB/T79–94
Ball Core Angle	90°
Ball Core Material	Cast steel, cast stainless steel
Body Structure	Part of the ball with V-notch
Seat Material	PTFE, reinforced PTFE, or stainless steel
Applicable Temperature	Normal type: –40 ~ 180°C; High-temp type: –20 ~ 450°C
Flow Characteristics	Approximately equal percentage (typical curve, see Appendix)
Actuator Model	DKI– I (electrically operated actuator with high control performance)
Input Signal	0–10 mA, 4–20 mA, 1–5 V DC
Basic Error	≤ ±2.5% of full travel
Backlash	≤ 2% of full travel
Dead Area	≤ 3.0% of full travel
Leakage	Soft seal: per JB/T7387–94 Table 2, Grade V

◇ External Dimensions

ZKJV–16 Model

DN (mm)	L	H1	H2	D1	n–φd
25	102	450	60	85	4–18
32	100	460	65	100	4–23
40	114	470	75	110	4–23
50	124	500	95	125	4–23
65	143	590	105	145	8–23
80	165	600	120	160	8–23
100	190	720	140	180	8–23
125	213	737	165	210	8–30
150	229	755	180	240	8–34
200	267	870	210	295	12–34
250	297	1070	240	355	12–41
300	330	1110	290	410	16–41
350	380	1145	330	470	16–41
400	420	1180	360	525	16–48

Electronic Servo ZDJV–16 Type Internal Actuator

DN (mm)	PS AUTOMATION CMBH			LNAR–KOSO			Unic–Z
	H1	L1	L2	H1	L1	L2	H1	L1	L2
25	388	182	90	321	56	225	277	98	110
32	406	182	90	339	56	225	295	98	110
40	416	182	90	349	56	225	305	98	110
50	475	182	90	408	56	265	364	98	110
65	568	210	105	463	56	255	379	123	133
80	593	210	105	473	56	255	389	123	133
100	677	252	131	486	56	255	402	123	133
125	701	252	131	560	68	270	426	123	133
150	711	252	131	580	68	270	/	/	/
200	771	252	131	685	80	335	/	/	/
250	/	/	/	/	/	/	/	/	/
300	/	/	/	/	/	/	/	/	/
350	/	/	/	/	/	/	/	/	/
400	/	/	/	/	/	/	/	/	/

External Dimensions – ZKJV-64 Model(mm)

DN	L	H1	H2	D1	n–φd (Bolt Hole Pattern)
25	102	450	60	85	4–18
32	102	460	65	100	4–23
40	114	470	75	110	4–23
50	124	500	95	125	4–23
65	143	590	105	145	8–23
80	165	600	120	160	8–23
100	194	720	140	180	8–23
125	213	737	165	210	8–30
150	229	835	185	240	8–34
200	243	875	205	295	12–34
250	297	1070	240	355	12–41
300	338	1110	290	410	16–41
350	380	1145	330	470	16–41
400	420	1180	360	525	16–48

Specification Applications

Industries

- Chemical Processing
- Petrochemical
- Oil & Gas
- Power Generation
- Pulp and Paper
- Water and Wastewater Treatment
Typical Applications:
- Flow Control: Precise regulation of liquids, gases, and steam
- Modulating Services: Integration into automated control systems for process optimization
- Abrasive and Viscous Fluids: Suitable for fluids containing fibers, particulates, or high viscosity
- Slurry Handling: Effective in applications involving slurry or sediment-laden fluids
