Size Range: DN40–DN1200
Pressure Range: PN6–PN16
End Connection: Wafer, Lug, or Flanged
Material: Ductile Iron or Carbon Steel Body with PTFE/FEP Lining
Seals: PTFE/FEP
Valves Design: Centered or Eccentric Fluorine-Lined Butterfly Valve
Face to Face: ISO 5752 / API 609
End Connection: ASME B16.5, EN 1092-1
Testing & Inspection: API 598, ISO 5208
Suitable Medium: Acidic, Alkaline, and Corrosive Fluids
The Fluorine-Lined Butterfly Valve is engineered for handling aggressive and corrosive media in industrial processes. Its fluorine-lined body ensures excellent chemical resistance, while the compact and durable design provides a cost-effective solution for various applications. This valve features easy installation and low maintenance.
Chemical Resistance: PTFE/FEP lining provides superior resistance to highly corrosive media.
Robust Construction: Built to withstand high-pressure environments and ensure long service life.
Easy Installation: Compact and lightweight design simplifies installation and maintenance.
Versatile Design: Suitable for both wafer, lug, and flanged connections.
Reliable Sealing: High-quality seals ensure leak-proof performance under demanding conditions.
Design and Manufacturing Standards: API 609, ASME B16.34
Structural Length Standard: ISO 5752 / API 609
Connection Forms Standards: ASME B16.5, EN 1092-1
Available Sizes (Caliber): DN40–DN1200
Pressure-Temperature Rating:
Standard: PN6–PN16 / ANSI Class 150
Pressure Range: 0.6 MPa to 1.6 MPa
Temperature Range: -29°C to 180°C
Chemical Processing Plants: Ideal for handling strong acids and alkalis.
Petrochemical Industries: Efficient for transporting corrosive substances.
Water Treatment Facilities: Used in the processing of water and wastewater.
Pharmaceutical Production: Suitable for sterile and clean operations.
