Hydraulic Actuated Slow Closed Butterfly Valve

Home » Products » Hydraulic Actuated Slow Closed Butterfly Valve

Hydraulic Actuated Slow Closed Butterfly Valve

Nominal Diameter: DN300 ~ 4000mm
Nominal: PN2.5 ~ 4.0MPa
Medium Temperature: ≤80 °C
Valve open time: 10 to 90 seconds (adjustable)
Fast Off Time: 1.5 to 20 seconds (adjustable)
Slow closing time: 6 ~ 90 seconds (adjustable)
Fast closing angle: 70° ± 10°
Slow cut angle: 20° ± 10°
Full open state Minimum flow resistance coefficient: 0.1
Optional Control power: AC220V, DC220V, DC110V, DC24V

Product Overview

The Hydraulic Actuated Slow Closed Butterfly Valve is designed for controlling the flow of liquids, gases, or slurries in a wide range of industrial applications. With its hydraulic actuator, this valve offers a slow closing function, which ensures a smooth and controlled closure, minimizing water hammer and reducing the risk of damage to the piping system. It is ideal for use in systems where a gradual shutoff is required to avoid sudden pressure surges.

The valve features a robust, durable construction, making it suitable for high-pressure applications. Its precision-engineered butterfly design allows for reliable flow regulation and tight sealing performance. The hydraulic actuator enables precise control over the opening and closing time, ensuring optimal operational efficiency. With excellent corrosion resistance and a reliable sealing mechanism, this valve is perfect for demanding environments in industries such as water treatment, power generation, and chemical processing.

Product Features

Fast Closing Time: Achieves a quick closing time of up to 0.5 seconds, ensuring emergency shutoff with high reliability.
Triple-Eccentric Metal Sealing Structure: Provides smooth and flexible opening and closing with zero leakage due to the advanced sealing technology.
Dual-Eccentric Soft Sealing Structure: For normal temperature media, this cost-effective soft seal structure ensures reliable sealing performance.
End-of-Close Buffer: Effectively prevents valve impact caused by inertia at the end of closure, protecting the system from damage.
Quick Close Options: Can utilize either a spring or an accumulator to achieve rapid closing, both methods ensuring safety and reliability.

Specification Parameters

Main Tech Parameters

Nominal Diameter (mm)	400 ~ 1600
Nominal Pressure (Mpa)	0.6	1	1.6	2.5
Test Pressure	0.9	1.5	2.4	3.75
Seal Test Pressure	0.66	1.1	1.76	2.75
Working Pressure (Mpa)	0.6	1	1.6
Applicable Medium	Water, Steam, Gas
Temperature Range (°C)	Soft Seal: ≤80°C; Hard Seal: ≤425°C

Main component materials

Component Name	Material
Valve Body, Butterfly Disc	Cast Iron, Cast Steel, Stainless Steel
Shaft	Stainless Steel
Seal Ring	Stainless Steel, NBR

Implementation standards

Standard Type	Standard Number
Design Reference	GB/T 12238, JB/T 5299, JB/T 8527
Flange Standard	GB/T 17241, GB/T 9113
Structure Length Standard	GB/T 12221
Pressure Test Standard	GB/T 13927

Connection Dimensions

DN	PN	L	L1	L2	L3	L4	Flange Standard
400	0.6	216	556	1449	320	440	GB/T 17241, GB/T 9113
400	1	216	556	1449	330	440	GB/T 17241, GB/T 9113
400	1.6	216	556	1449	370	440	GB/T 17241, GB/T 9113
450	0.6	222	556	1449	395	490	GB/T 17241, GB/T 9113
450	1	222	556	1449	400	490	GB/T 17241, GB/T 9113
450	1.6	222	556	1449	410	490	GB/T 17241, GB/T 9113
500	0.6	229	580	1449	415	490	GB/T 17241, GB/T 9113
500	1	229	580	1449	420	490	GB/T 17241, GB/T 9113
500	1.6	229	580	1449	425	490	GB/T 17241, GB/T 9113
600	0.6	267	625	1449	460	490	GB/T 17241, GB/T 9113
600	1	267	625	1449	470	490	GB/T 17241, GB/T 9113
600	1.6	267	625	1820	470	490	GB/T 17241, GB/T 9113
700	0.6	292	625	1449	550	490	GB/T 17241, GB/T 9113
700	1	292	625	1820	570	545	GB/T 17241, GB/T 9113
700	1.6	292	625	1820	625	545	GB/T 17241, GB/T 9113
800	0.6	318	625	1449	640	490	GB/T 17241, GB/T 9113
800	1	318	625	1820	660	545	GB/T 17241, GB/T 9113
800	1.6	318	625	1820	700	545	GB/T 17241, GB/T 9113
900	0.6	330	625	1820	710	545	GB/T 17241, GB/T 9113
900	1	330	625	1820	725	545	GB/T 17241, GB/T 9113
900	1.6	330	675	1820	760	545	GB/T 17241, GB/T 9113
1000	0.6	410	675	2180	770	610	GB/T 17241, GB/T 9113
1000	1	410	675	2180	790	610	GB/T 17241, GB/T 9113
1000	1.6	410	675	2180	875	610	GB/T 17241, GB/T 9113
1200	0.6	470	675	2180	890	610	GB/T 17241, GB/T 9113
1200	1	470	675	2180	915	610	GB/T 17241, GB/T 9113
1200	1.6	470	675	2180	1000	610	GB/T 17241, GB/T 9113
1400	0.6	530	729	2180	1025	720	GB/T 17241, GB/T 9113
1400	1	530	729	2180	1045	720	GB/T 17241, GB/T 9113
1400	1.6	530	781	2180	1020	720	GB/T 17241, GB/T 9113
1600	0.6	600	781	2180	1140	720	GB/T 17241, GB/T 9113
1600	1	600	781	2180	1150	720	GB/T 17241, GB/T 9113
1600	1.6	600	781	2520	1170	960	GB/T 17241, GB/T 9113

Specification Applications

Water Treatment Plants: To regulate water flow efficiently and avoid abrupt changes in pressure, preserving the integrity of the entire system.
Oil & Gas Industry: To control the flow of fluids, offering enhanced sealing and minimal risk of leaks under high-pressure conditions.
Chemical Processing Plants: Suitable for handling aggressive fluids, it provides reliable operation and extends the life of the valve by controlling the closure speed.
Power Stations: Ensures slow and steady valve operation to protect critical equipment from sudden pressure changes.
HVAC Systems: Offers smooth and efficient control in heating and cooling systems, preventing damage to pipes and pumps caused by sudden pressure surges.
