Size Range: 1/2″ to 2″ (DN15 to DN50)
Pressure Range: Class 800, 1500, 2500
End Connection: Socket Weld or Threaded Ends
Material: Carbon Steel
Seals: Metal-to-Metal Sealing
Valve Design: Y-pattern with bolted bonnet
Face to Face: Conforms to ASME B16.10
Testing & Inspection: Per API 598
Suitable Medium: Steam, gas, oil, and other neutral liquids
The Y Pattern Globe Valve is designed for efficient flow control with minimal pressure loss. Its oblique body design offers smoother flow compared to conventional globe valves, making it ideal for high-pressure and high-temperature applications such as steam, oil, and gas systems.
Constructed from high-grade carbon or stainless steel, it ensures durability, corrosion resistance, and long service life. The valve features a non-rising stem, precision-machined seat, and tight shut-off capability, conforming to API 600 or equivalent international standards.
Y-pattern body design reduces flow resistance and pressure drop.
High-strength forged or cast body ensures durability under high pressure and temperature.
Precision-machined seat and disc provide tight sealing and reliable shut-off.
Non-rising stem design saves installation space and prevents stem damage.
Available in various materials (carbon steel, stainless steel, alloy steel) for different media and conditions.
Meets international standards such as API 600 and ASME B16.34.
Design and Manufacturing Standards: Conforms to API 602 and ASME B16.34
Structural Length Standard: Complies with ASME B16.10
Connection Forms Standards: Socket Weld Ends per ASME B16.11 or Threaded Ends per ASME B1.20.1
Available Sizes (Caliber): 1/2″ to 2″ (DN15 to DN50)
Pressure-Temperature Rating:
Standard: Class 800, 1500, 2500
Pressure Range: Up to 3700 psi
Temperature Range: -29°C to 425°C (-20°F to 800°F), depending on material
Power plants – steam lines and condensate systems
Oil & gas industry – high-pressure and high-temperature pipelines
Petrochemical plants – process control and isolation service
Refineries – throttling and shut-off for hot fluids and gases
Marine and boiler systems – feedwater and blowdown lines
